ESD Static Dissipative Tabulatum Tiles

Introductio Producti

ESD Tegulae contabulationes modulares sunt anti-statice PVC tegulae ex composito materiae dissolutivae electrostaticae (ESD). Institui possunt ut singulae tegulae vel in iunctura connexae, crassitudine typica ab 2.0-3.0mm vagantibus. Hae tegulae proprietates anti-staticas permanentes praebent, resistentiam lapsus, resistentiam gerunt et resistentiam chemicam corrosioni praebent. Facile sunt reponere vel conservare et apta sunt centris electronicis, officinae electronicae, laboratoria, et exquisita loca medica.

Core Commoda

Modular Design: Removable and easy to replace, idonea ad partial sustentationem aut nativus consilia institutionis.
Permanens Anti-static: Conductivae/dissipativae proprietates stabiles sunt et per tempus non decedunt.
Gere-resistentes et Durabiles: Apta ad altas pedites negotiandi areas et regiones frequenti apparatu motus.
Lapsus resistens et Ignis repugnans: Meets BF1 ignis rating, friction coëfficiens altus, periculum lapsus minuens.
Corrosio chemica repugnans: Capax tractandi purgatio agentibus mundandis et quibusdam oeconomiis.

Locum missiones

Microelectronics officinas fabricandi, cellas ministrantes, plantas semiconductores, conventus SMT/PCB et areas probativas, purgamenta medica, areas experimentales aerospace.

Technical Parameters

Crassitudo: 2.0-3.0mm
Conductivity: 10⁴ – 10⁹ Ω (customizable)
Dimensiones: 600×600mm / 610×610mm / 914×914mm / 900×900mm
Superficies curatio: expolita / Matte
Pondus: Proxime 3980-5700g/m², crassitudine fretus.

Item	Signa	Specifications
Crassitudo	SJ/T11236-2020	2.0, 2.5, 3.0mm
	SO 24346(EN428)
Electrical Resistentia	SJ/T11236-2020	110 - 110Ω	110 - 1100
	EN 1081	10 - 10Ω	10 - 100
Dicens Voltage	AATCC - 134	50V	100V
	SJ/T 10694 - 2006	<100V <2 KV
	EN1815
Corpus intentionum	ANSI ESD STM97.2	<100V
Static Decay	GJB3007A - 2009	≤2(Sec) 0.01(Sec)
	Federal Test Methodo 1018 Methodo 4046
Resistentia ad gere	SJ/T11236-2020	≤0.03 g/cm² P
	EN660 - 2
Ignis Resistentia	SJ/T11236-2020	FV - 0 B(B - 51,t0) Classis B1 - S1
	GB8624 - 2012
	ASTM E648 - 2009a
	EN13501 - 1
Dimensiona	ASTM F2199	≤0.05 % ≤0.05 %
	ISO 23999 - 2018(EN434)
Resistentia labi infectum	DIN 51130	R9
RELICTUM Indentation	GB/T4085 - 2015	0.15mm≤lgs0.40mm 0.01mm
	ISO 24343 - 1(EN433)
Color Fastness	SO 105 - B02	≥6
Chemical Products Resistentia	EN ISO26987(EN423)	Bene
Toxicus Testis	GB18586 - 2001	Bene
	EN 71 - 3
